Duct MOQ 2km Drum Box GYTA 2 4 8 12 24 32 48 96 288 144f Optical Fiber Cable Black Color Opgw Fiber Cable

Basic Info

Model NO.	OPGW cable
Application	Communication
Type	Single-mode Fiber
Connection Structure	SC
Material Shape	Round Wire
Allowed Lateral Pressure	100(N/100mm)<1000(N/100mm)
Allowed Tensile Strength	1000N<10000N
Core	Single Mode/Multi Mode
Certification	RoHS, CE, ISO9001
Brand	OEM
Sheath Material	Acs
Loose Tube Material	PBT
Outer Sheath	HDPE
Fiber Size	G652. G655
Mode	Single Mode or Multi Mode
Number of Cores	12---144 Cores
Diameter of Acs Wire	2.4-3.5 mm
Tube	Stainless Steel Tube
Cable Structure	Stranding Sst Opgw Cable
Transport Package	Steel-Wooden Drum, Steel Drum or Wooden Drum
Trademark	YIXUN or OEM
Origin	China/Zhejiang
HS Code	854470000
Production Capacity	8000km/Week

Product Description

Deacription:

OPGW is an outdoor use optical fiber cable suitable for duct and aerial applications. We supply OPGW fiber optic cable from 2 fiber cores to 12 fiber cores. Both single mode type and multimode types are available.

·The fibers, 260μm, are positioned in a loose tube made of a high modulus plastic. · The tubes are filled with a water-resistant filling compound. · The tube is wrapped with a layer of corrugated steel tape longitudinally. · Between the corrugated steel tape and the loose tube water-blocking material is applied to keep the cable compact and watertight. · Two parallel steel wires are placed at the two sides of the steel tape. · The cable is completed with PE sheath.

Feature 6 core fiber optic cable

Low dispersion and attenuation Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties.6 core fiber optic cable The armoring of corrugate steel tape make cable have nice properties of moisture resistance and crush resistance.6 core fiber optic cable Operating Temperature : -40~+60 ºC

Cable Parameters
Items		Specifications
Fiber Count		2~24
Colored Coating Fiber	Dimension	260µm±15µm
	Color	Blue, Orange, Green, Brown, Gray, White
Loose Tube Dimension 2.10mm±0.05mm	Dimension	2.10mm±0.05mm
	Material	PBT
	Color	Natural
Strength Member	Diameter	1.0mm
	Material	Steel
Outer Jacket	Dimension	8.0mm±0.1mm
	Material	PE
	Color	Black

Technical Parameter
Fiber Count	Cable Diameter (mm)	Cable Weight (kg/km)	Tensile Strength Long/Short Term (N)	Crush Resistance Long/Short Term (N/100mm)	Bending Radius Static/Dynamic (mm)
2~12	10.6	124	1000/3000	1000/3000	10D/20D
14~24	12.0	147	1000/3000	1000/3000	10D/20D

Features

1. Up to 144 fibers2. Cable diameter and weight approximate with another ground wire. Less additional load to tower, high tensile strength.3. Excellent stainless steel tube stranding technology make the fibers have good secondary excess length and allow the fibers,free movement in the tube. Which keeps the fiber stress-free while the cable is subjected to longitudinal stress.

Application

1.The Optical fiber composite ground wire [OPGW] is suitable for installation on new power lines withdouble function of ground wire and communication. Especially for installation on normal voitage andextra highvoltage power lines. OPGW can replace conventional ground wire of old power line withincreasing fiber communication function. They conduct short circuit current and provide lightning resistance.2. OPGW cable is mainly used in 500KV, 220KV and 110KV lines, limited by power cut, security and other elements, mostly used innew lines. Its applications are:high pressure over 110kv, with a longer span (usually over 250M).

Why Choose Us
YIXUN knows deep down that our purpose is to meet the needs of our customers.We learn about the supply chain and know that the difficulties we are facing are also the same as those of our customers.In this way, by understanding what our own needs are, we can think outside the box to understand the needs of our customers.If you talk with YIXUN, we will do exactly according to documents: How to find an honest supplier? (We will send you if you need).We hope that customers can feel relaxed and happy when negotiating with our company, not only can complete the procurement work efficiently and worry-free but also to improve your ability of re-sell.What kind of service we can provide?1.Latest market information per month2.Market research report3.Solutions of supplier's dishonest problem4.Solutions of supplier's poor service5.Soulutions of supplier's quality control problem 6.Soulutions of supplier's lead time problem 7.Support solutions replace price list8.Channels for complaints9.25 Years of quality warranty assurance. 10.Market protection. 11.Solutions of order follow-up. 12.Support sales methods and strategies.



FAQ
(1)Q: Are you a manufacturer or a trading company?
A: We are a Industry and trade integration with 12 years production experience.
(2)Q: Can you print our logo or company name in cable?
A: Yes,we can print your logo or company name on products.
(3)Q:Can you accept customize or design for us?
A: Yes, all communication cables are customized in our own factory and we can design for you according to your requirement.
(4)Q:Is it possible to get a free sample ?
A: Yes, samples are free,and shipping cost have to be paid by your esteemed company. But we will return the sample cost to you when we receiving your initial order.
(5)Q:What is your MOQ ?
A: Usually, MOQ is 100 thousand meters.
(6)Q:If I want to purchase,how to pay?
A: Usually, we do T/T in 30% deposit before production,70% balance against copy of B/L. Also payment terms are negotiable depending on customer's request.
