High Quality 12fibers Sc/APC Bunch Fiber Optic Pigtail with Good Price

Basic Info

Model NO.	bunch Fiber Optic Pigtail
Core	Single Core
Certification	RoHS, ISO9001
Brand	OEM
Sheath Material	Crosslinking
Insertion Loss	Less Than 0.3dB
Return Loss	More Than 55dB
Operating Temperature	-20~75 Degree
Storage Temperature	-40~75 Degree
Apex Offset	Less Than 50um
Cable Material	PVC/LSZH
Fiber Type	G652D, G657A1
Cable Type	Distribution
Cable Od	0.9mm, 2.0mm, 3.0mm
Connector	Sc/APC
Transport Package	Carton Box
Specification	fiber optic patch cord
Trademark	Opelink
Origin	China
HS Code	85367000

Product Description

High Quality 12Fibers Sc/APC bunch Fiber Optic Pigtail with Good Price

Features:Low insertion loss and High Return LossGood durabilityGood exchangeabilityHigh temperature stabilitycompliant with standards of Telcordia GR-326-COREApplication:Optical Fiber Communication SystemsOptical Access NetworkFiber optic data transmissionOptical Fiber CATVLocal Area Network (LAN)Test EquipmentDescription:Connector:SC,FC,ST,LC,MU,MTRJ,E2000, etcPolishing type:PC,UPC,APCFiber Type:Singlemode(G652D,G657A),Multimode(OM1,OM2,OM3,OM4)Fiber cable:Simplex,Duplex,Multi-core,Ribbon,Distribution, Armoured, etcCable OD:0.9mm,2.0mm,3.0mm,etcCable Material:PVC-OFNR,PVC-OFNP,LSZH, etcPatchcord Length:1m,2m,etcOptical Specifications:

Parameter	Singlemode Patchcord			Multimode Patchcord
Polishing Type	PC	UPC	APC	PC
Insertion loss(dB)	<=0.3dB,MTRJ<=0.5dB	<=0.3dB	<=0.3dB	<=0.3dB,MTRJ<=0.5dB
Return loss(dB)	>=45dB,MTRJ>=35dB	>=55dB	>=65dB
Operating temperature	-20ºC~75ºC
Storage Temperature	-40ºC~75ºC
100 mating cycles loss	I.L changed≤0.1dB
Durability	>1000 cycles

Geometric Specification:

Parameter	PC Polishing		APC Polishing
	SC Type	LC Type
R.O.C	10~25mm	7~25mm	5~12mm
Apex Offset	<50um	<50um	<50um
Fiber Height	-125nm-50nm		-100nm-100nm
Polishing Angle			8°± 0.3°

Ordering information:

Type	Fiber Core	Cable Type	Cable OD	Cable Material	Cable Color	Connector (A End -B End)	Patchcord Length
PT=Patchcord PY=Pigtail	S1=G652D S2= G657A1 M1=50/125 M2=62.5/125 M3=OM3 M4=OM4 XX=other	01=simplex 02=Duplex 03=Armoured 04=Distribution 05=Ribbon 06=breakout XX=other	01=OD 0.9mm 02=OD 2.0mm 03=OD 3.0mm XX=other	1=PVC(R) 2=PVC(P) 2=LSZH	01=Blue 02=Orange 03=Green 04=Brown 05=Slate 06=White 07=Red 08=Black 09=Yellow 10=Violet 11=Rose 12=Aqua 13=12Color XX=other	01=SC 02=FC 03=ST 04=LC 05= E2000 06=SC/APC (Cone Type) 07= SC/APC (Step Type) 08= FC/APC (Cone Type ) 09= FC/APC (Step Type) 10=LC/APC 11=E2000/APC 12=MTRJ 13=MPO/PC 14=MPO/APC 15=D4 16=DIN 17=LX5 18=FDDI 00=None XX=other	005=0.5m 010=1.0m 020=2m 025=2.5m XXX=other



----------------------------------------------------FAQ---------------------------------------------------

Q1. Can I have a sample order for this product? What' MOQ of it?
A: Yes welcome send sample order for test. MOQ is 1 piece.

Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks.

Q3: What' s the payment term
A: We usually use TT(Telegram Transfer) in advance, Western Union. Other payment method is negotiable.

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5: What' s the freight of it?
A: It depends on the order quantity. We have some reliable ship forwarders. We will offer cost effective method for you.

Q6: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty according to different products.

Q7: What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.
